33 :TRIGger Commands
:TRIGger[:EDGE]:SLOPe
<polarity> (see
page 1168)
:TRIGger[:EDGE]:SLOPe
? (see page 1168)
<polarity> ::= {POSitive |
NEGative | EITHer | ALTernate}
:TRIGger[:EDGE]:SOURc
e <source> (see
page 1169)
:TRIGger[:EDGE]:SOURc
e? (see page 1169)
<source> ::= {CHANnel<n> |
EXTernal | LINE | WGEN | WGEN1 |
WGEN2 | WMOD} for the DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal | LINE |
WGEN | WGEN1 | WGEN2 | WMOD} for
the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
Note: WGEN and WGEN1 are
equivalent.
Note: WGEN2 only available on
models with 2 WaveGen outputs.
Table 147 :TRIGger[:EDGE] Commands Summary (continued)
Command Query Options and Query Returns
