Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 121
:MEASure:VAVerage
[<interval>][,<source
>] (see page 542)
:MEASure:VAVerage?
[<interval>][,<source
>] (see page 542)
<interval> ::= {CYCLe | DISPlay}
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= calculated
average voltage in NR3 format
:MEASure:VBASe
[<source>] (see
page 543)
:MEASure:VBASe?
[<source>] (see
page 543)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<base_voltage> ::= voltage at the
base of the selected waveform in
NR3 format
:MEASure:VMAX
[<source>] (see
page 544)
:MEASure:VMAX?
[<source>] (see
page 544)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= maximum
voltage of the selected waveform
in NR3 format
Table 19 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
