Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 127
:MEASure:RDSon
[<source1>][,<source2
>] (see page 572)
:MEASure:RDSon?
[<source1>][,<source2
>] (see page 572)
<source1>, <source2> ::=
{CHANnel<n>| FUNCtion<m> |
MATH<m> | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the VCE(sat)
value in NR3 format
:MEASure:REACtive
[<source1>][,<source2
>] (see page 573)
:MEASure:REACtive?
[<source1>][,<source2
>] (see page 573)
<source1>, <source2> ::=
{CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the reactive
power value in NR3 format
:MEASure:REAL
[<source>] (see
page 574)
:MEASure:REAL?
[<source>] (see
page 574)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<return_value> ::= the real power
value in NR3 format
:MEASure:RIPPle
[<source>] (see
page 575)
:MEASure:RIPPle?
[<source>] (see
page 575)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the output
ripple value in NR3 format
Table 20 :MEASure Power Commands Summary (continued)
Command Query Options and Query Returns
