1270 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
35 :WGEN<w> Commands
:WGEN<w>:ARBitrary:IN
Terpolate {{0 | OFF}
| {1 | ON}} (see
page 1279)
:WGEN<w>:ARBitrary:IN
Terpolate? (see
page 1279)
{0 | 1}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:ST
ORe <source> (see
page 1280)
n/a <source> ::= {CHANnel<n> |
WMEMory<r> | FUNCtion<m> |
MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FREQuency
<frequency> (see
page 1281)
:WGEN<w>:FREQuency?
(see page 1281)
<frequency> ::= frequency in Hz
in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FUNCtion
<signal> (see
page 1282)
:WGEN<w>:FUNCtion?
(see page 1285)
<signal> ::= {SINusoid | SQUare |
RAMP | PULSe | NOISe | DC | SINC
| EXPRise | EXPFall | CARDiac |
GAUSsian | ARBitrary}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FUNCtion:PUL
Se:WIDTh <width> (see
page 1286)
:WGEN<w>:FUNCtion:PUL
Se:WIDTh? (see
page 1286)
<width> ::= pulse width in
seconds in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FUNCtion:RAM
P:SYMMetry <percent>
(see page 1287)
:WGEN<w>:FUNCtion:RAM
P:SYMMetry? (see
page 1287)
<percent> ::= symmetry
percentage from 0% to 100% in NR1
format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FUNCtion:SQU
are:DCYCle <percent>
(see page 1288)
:WGEN<w>:FUNCtion:SQU
are:DCYCle? (see
page 1288)
<percent> ::= duty cycle
percentage from 20% to 80% in NR1
format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:MODulation:A
M:DEPTh <percent>
(see page 1289)
:WGEN<w>:MODulation:A
M:DEPTh? (see
page 1289)
<percent> ::= AM depth percentage
from 0% to 100% in NR1 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:A
M:FREQuency
<frequency> (see
page 1290)
:WGEN<w>:MODulation:A
M:FREQuency? (see
page 1290)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
<w> ::= 1 in NR1 format
Table 159 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
