36 :WMEMory<r> Commands
Control reference waveforms.
Table 160 :WMEMory<r> Commands Summary
Command Query Options and Query Returns
:WMEMory<r>:CLEar
(see page 1319)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
:WMEMory<r>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 1320)
:WMEMory<r>:DISPlay?
(see page 1320)
<r> ::= 1 to (# ref waveforms) in
NR1 format
{0 | 1}
:WMEMory<r>:LABel
<string> (see
page 1321)
:WMEMory<r>:LABel?
(see page 1321)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
:WMEMory<r>:SAVE
<source> (see
page 1322)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
NOTE: Math functions whose x-axis
is not frequency can be saved as
reference waveforms.
:WMEMory<r>:SKEW
<skew> (see page 1323)
:WMEMory<r>:SKEW?
(see page 1323)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<skew> ::= time in seconds in NR3
format
:WMEMory<r>:YOFFset
<offset>[suffix] (see
page 1324)
:WMEMory<r>:YOFFset?
(see page 1324)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<offset> ::= vertical offset
value in NR3 format
[suffix] ::= {V | mV}
