Keysight Technologies InfiniiVision MSO-X 4022A

138 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 24 :RECall Commands Summary
Command Query Options and Query Returns
:RECall:ARBitrary:[ST
ARt] [<file_spec>][,
<column>][,
<wavegen_id>] (see
page 715)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<column> ::= Column in CSV file
to load. Column number starts
from 1.
<internal_loc> ::= 0-3; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
<wavegen_id> ::= {WGEN1 | WGEN2}
:RECall:DBC[:STARt]
[<file_name>] [,
<serialbus>] (see
page 716)
n/a <file_name> ::= quoted ASCII
string
If extension included in file
name, it must be ".dbc".
<serialbus> ::= {SBUS<n>}
<n> ::= 1 to (# of serial bus) in
NR1 format
:RECall:FILename
<base_name> (see
page 717)
:RECall:FILename?
(see page 717)
<base_name> ::= quoted ASCII
string
:RECall:LDF[:STARt]
[<file_name>] [,
<serialbus>] (see
page 718)
n/a <file_name> ::= quoted ASCII
string
If extension included in file
name, it must be ".ldf".
<serialbus> ::= {SBUS<n>}
<n> ::= 1 to (# of serial bus) in
NR1 format
:RECall:MASK[:STARt]
[<file_spec>] (see
page 719)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-3; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:RECall:PWD
<path_name> (see
page 720)
:RECall:PWD? (see
page 720)
<path_name> ::= quoted ASCII
string
