Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 141
:SAVE:RESults:FORMat:
SEGMented {{0 | OFF}
| {1 | ON}} (see
page 745)
:SAVE:RESults:FORMat:
SEGMented? (see
page 745)
{0 | 1}
:SAVE:SETup[:STARt]
[<file_spec>] (see
page 746)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-9; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:SAVE:WAVeform[:STARt
] [<file_name>] (see
page 747)
n/a <file_name> ::= quoted ASCII
string
:SAVE:WAVeform:FORMat
<format> (see
page 748)
:SAVE:WAVeform:FORMat
? (see page 748)
<format> ::= {ASCiixy | CSV |
BINary | NONE}
:SAVE:WAVeform:LENGth
<length> (see
page 749)
:SAVE:WAVeform:LENGth
? (see page 749)
<length> ::= 100 to max. length;
an integer in NR1 format
:SAVE:WAVeform:LENGth
:MAX {{0 | OFF} | {1
| ON}} (see page 750)
:SAVE:WAVeform:LENGth
:MAX? (see page 750)
{0 | 1}
:SAVE:WAVeform:SEGMen
ted <option> (see
page 751)
:SAVE:WAVeform:SEGMen
ted? (see page 751)
<option> ::= {ALL | CURRent}
:SAVE:WMEMory:SOURce
<source> (see
page 752)
:SAVE:WMEMory:SOURce?
(see page 752)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
NOTE: Only ADD or SUBtract math
operations can be saved as
reference waveforms.
<return_value> ::= <source>
:SAVE:WMEMory[:STARt]
[<file_name>] (see
page 753)
n/a <file_name> ::= quoted ASCII
string
If extension included in file
name, it must be ".h5".
Table 25 :SAVE Commands Summary (continued)
Command Query Options and Query Returns
