Keysight Technologies InfiniiVision MSO-X 4022A

146 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:CAN:TRIGger:
SYMBolic:MESSage
<name> (see page 804)
:SBUS<n>:CAN:TRIGger:
SYMBolic:MESSage?
(see page 804)
<name> ::= quoted ASCII string
:SBUS<n>:CAN:TRIGger:
SYMBolic:SIGNal
<name> (see page 805)
:SBUS<n>:CAN:TRIGger:
SYMBolic:SIGNal? (see
page 805)
<name> ::= quoted ASCII string
:SBUS<n>:CAN:TRIGger:
SYMBolic:VALue <data>
(see page 806)
:SBUS<n>:CAN:TRIGger:
SYMBolic:VALue? (see
page 806)
<data> ::= value in NR3 format
Table 28 :SBUS<n>:CAN Commands Summary (continued)
Command Query Options and Query Returns
Table 29 :SBUS<n>:CXPI Commands Summary
Command Query Options and Query Returns
:SBUS<n>:CXPI:BAUDrat
e <baudrate> (see
page 809)
:SBUS<n>:CXPI:BAUDrat
e? (see page 809)
<baudrate> ::= integer from 9600
to 40000 in 100 b/s increments.
:SBUS<n>:CXPI:PARity
{{0 | OFF} | {1 |
ON}} (see page 810)
:SBUS<n>:CXPI:PARity?
(see page 810)
{0 | 1}
:SBUS<n>:CXPI:SOURce
<source> (see
page 811)
:SBUS<n>:CXPI:SOURce?
(see page 811)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:CXPI:TOLeran
ce <percent> (see
page 812)
:SBUS<n>:CXPI:TOLeran
ce? (see page 812)
<percent> ::= from 1-30, in NR1
format.
:SBUS<n>:CXPI:TRIGger
<mode> (see page 813)
:SBUS<n>:CXPI:TRIGger
? (see page 814)
<mode> ::= {SOF | EOF | PTYPe |
ID | DATA | LDATa | CRCerror |
PARityerror | IBSerror | IFSerror
| FRAMingerror | DLENgtherror |
SAMPleerror | ALLerrors |
SLEepframe | WAKeuppulse}
:SBUS<n>:CXPI:TRIGger
:IDFilter {{0 | OFF}
| {1 | ON}} (see
page 815)
:SBUS<n>:CXPI:TRIGger
:IDFilter? (see
page 815)
{0 | 1}
:SBUS<n>:CXPI:TRIGger
:PTYPe {{0 | OFF} |
{1 | ON}} (see
page 816)
:SBUS<n>:CXPI:TRIGger
:PTYPe? (see page 816)
{0 | 1}
