Keysight Technologies InfiniiVision MSO-X 4022A

148 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:FLEXray:CHAN
nel <channel> (see
page 828)
:SBUS<n>:FLEXray:CHAN
nel? (see page 828)
<channel> ::= {A | B}
n/a :SBUS<n>:FLEXray:COUN
t:NULL? (see page 829)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:COUN
t:RESet (see page 830)
n/a n/a
n/a :SBUS<n>:FLEXray:COUN
t:SYNC? (see page 831)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:FLEXray:COUN
t:TOTal? (see
page 832)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:SOUR
ce <source> (see
page 833)
:SBUS<n>:FLEXray:SOUR
ce? (see page 833)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
:SBUS<n>:FLEXray:TRIG
ger <condition> (see
page 834)
:SBUS<n>:FLEXray:TRIG
ger? (see page 834)
<condition> ::= {FRAMe | ERRor |
EVENt}
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE
<error_type> (see
page 835)
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE? (see
page 835)
<error_type> ::= {ALL | HCRC |
FCRC}
:SBUS<n>:FLEXray:TRIG
ger:EVENt:AUToset
(see page 836)
n/a n/a
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID
<frame_id> (see
page 837)
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID?
(see page 837)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
:SBUS<n>:FLEXray:TRIG
ger:EVENt:TYPE
<event> (see page 838)
:SBUS<n>:FLEXray:TRIG
ger:EVENt:TYPE? (see
page 838)
<event> ::= {WAKeup | TSS | {FES
| DTS} | BSS}
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCBase
<cycle_count_base>
(see page 839)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCBase?
(see page 839)
<cycle_count_base> ::= integer
from 0-63
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCRepetitio
n
<cycle_count_repetiti
on> (see page 840)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:CCRepetitio
n? (see page 840)
<cycle_count_repetition> ::=
{ALL | <rep #>}
<rep #> ::= integer values 2, 4,
8, 16, 32, or 64
Table 30 :SBUS<n>:FLEXray Commands Summary (continued)
Command Query Options and Query Returns
