Keysight Technologies InfiniiVision MSO-X 4022A

164 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 42 :SEARch:PEAK Commands Summary
Command Query Options and Query Returns
:SEARch:PEAK:EXCursio
n <delta_level> (see
page 1010)
:SEARch:PEAK:EXCursio
n? (see page 1010)
<delta_level> ::= required
change in level to be recognized
as a peak, in NR3 format.
:SEARch:PEAK:NPEaks
<number> (see
page 1011)
:SEARch:PEAK:NPEaks?
(see page 1011)
<number> ::= max number of peaks
to find, 1-11 in NR1 format.
:SEARch:PEAK:SOURce
<source> (see
page 1012)
:SEARch:PEAK:SOURce?
(see page 1012)
<source> ::= {FUNCtion<m> |
MATH<m>} (must be an FFT
waveform)
<m> ::= 1 to 4 in NR1 format
:SEARch:PEAK:THReshol
d <level> (see
page 1013)
:SEARch:PEAK:THReshol
d? (see page 1013)
<level> ::= necessary level to be
considered a peak, in NR3 format.
Table 43 :SEARch:RUNT Commands Summary
Command Query Options and Query Returns
:SEARch:RUNT:POLarity
<polarity> (see
page 1015)
:SEARch:RUNT:POLarity
? (see page 1015)
<polarity> ::= {POSitive |
NEGative | EITHer}
:SEARch:RUNT:QUALifie
r <qualifier> (see
page 1016)
:SEARch:RUNT:QUALifie
r? (see page 1016)
<qualifier> ::= {GREaterthan |
LESSthan | NONE}
:SEARch:RUNT:SOURce
<source> (see
page 1017)
:SEARch:RUNT:SOURce?
(see page 1017)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:SEARch:RUNT:TIME
<time>[suffix] (see
page 1018)
:SEARch:RUNT:TIME?
(see page 1018)
<time> ::= floating-point number
in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
Table 44 :SEARch:TRANsition Commands Summary
Command Query Options and Query Returns
:SEARch:TRANsition:QU
ALifier <qualifier>
(see page 1020)
:SEARch:TRANsition:QU
ALifier? (see
page 1020)
<qualifier> ::= {GREaterthan |
LESSthan}
:SEARch:TRANsition:SL
OPe <slope> (see
page 1021)
:SEARch:TRANsition:SL
OPe? (see page 1021)
<slope> ::= {NEGative | POSitive}
