172 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
5 Commands Quick Reference
:SBUS<n>:I2S:CLOCk:SL
OPe <slope> (see
page 948)
:SBUS<n>:I2S:CLOCk:SL
OPe? (see page 948)
<slope> ::= {NEGative | POSitive}
:SBUS<n>:I2S:RWIDth
<receiver> (see
page 949)
:SBUS<n>:I2S:RWIDth?
(see page 949)
<receiver> ::= 4-32 in NR1 format
:SBUS<n>:I2S:SOURce:C
LOCk <source> (see
page 950)
:SBUS<n>:I2S:SOURce:C
LOCk? (see page 950)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:SOURce:D
ATA <source> (see
page 951)
:SBUS<n>:I2S:SOURce:D
ATA? (see page 951)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:SOURce:W
SELect <source> (see
page 952)
:SBUS<n>:I2S:SOURce:W
SELect? (see page 952)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:TRIGger
<operator> (see
page 953)
:SBUS<n>:I2S:TRIGger?
(see page 953)
<operator> ::= {EQUal | NOTequal
| LESSthan | GREaterthan |
INRange | OUTRange | INCReasing |
DECReasing}
:SBUS<n>:I2S:TRIGger:
AUDio <audio_ch> (see
page 955)
:SBUS<n>:I2S:TRIGger:
AUDio? (see page 955)
<audio_ch> ::= {RIGHt | LEFT |
EITHer}
Table 32 :SBUS<n>:I2S Commands Summary (continued)
Command Query Options and Query Returns
