Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 185
:TRIGger:ZONE<n>:PLAC
ement <width>,
<height>, <x_center>,
<y_center> (see
page 1229)
:TRIGger:ZONE<n>:PLAC
ement? (see page 1229)
<width> ::= width of zone in
seconds
<height> ::= height of zone in
volts
<x_center> ::= center of zone in
seconds
<y_center> ::= center of zone in
volts
<n> ::= 1-2 in NR1 format
n/a :TRIGger:ZONE<n>:VALi
dity? (see page 1230)
<value> ::= {VALid | INValid |
OSCReen}
<n> ::= 1-2 in NR1 format
:TRIGger:ZONE<n>:STAT
e {{0 | OFF} | {1 |
ON}} (see page 1231)
:TRIGger:ZONE<n>:STAT
e? (see page 1231)
{0 | 1}
<n> ::= 1-2 in NR1 format
Table 70 :TRIGger:ZONE Commands Summary (continued)
Command Query Options and Query Returns
Table 71 :WAVeform Commands Summary
Command Query Options and Query Returns
:WAVeform:BYTeorder
<value> (see
page 1241)
:WAVeform:BYTeorder?
(see page 1241)
<value> ::= {LSBFirst | MSBFirst}
n/a :WAVeform:COUNt? (see
page 1242)
<count> ::= an integer from 1 to
65536 in NR1 format
n/a :WAVeform:DATA? (see
page 1243)
<binary block length bytes>,
<binary data>
For example, to transmit 1000
bytes of data, the syntax would
be: #800001000<1000 bytes of
data><NL>
8 is the number of digits that
follow
00001000 is the number of bytes
to be transmitted
<1000 bytes of data> is the
actual data
:WAVeform:FORMat
<value> (see
page 1245)
:WAVeform:FORMat?
(see page 1245)
<value> ::= {WORD | BYTE | ASCII}
