Keysight Technologies InfiniiVision MSO-X 4022A

188 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 72 :WGEN<w> Commands Summary
Command Query Options and Query Returns
:WGEN<w>:ARBitrary:BY
Teorder <order> (see
page 1274)
:WGEN<w>:ARBitrary:BY
Teorder? (see
page 1274)
<order> ::= {MSBFirst | LSBFirst}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:DA
TA {<binary> |
<value>, <value> ...}
(see page 1275)
n/a <binary> ::= floating point
values between -1.0 to +1.0 in
IEEE 488.2 binary block format
<value> ::= floating point values
between -1.0 to +1.0 in
comma-separated format
<w> ::= 1 or 2 in NR1 format
n/a :WGEN<w>:ARBitrary:DA
TA:ATTRibute:POINts?
(see page 1276)
<points> ::= number of points in
NR1 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:DA
TA:CLEar (see
page 1277)
n/a <w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:DA
TA:DAC {<binary> |
<value>, <value> ...}
(see page 1278)
n/a <binary> ::= decimal 16-bit
integer values between -512 to
+511 in IEEE 488.2 binary block
format
<value> ::= decimal integer
values between -512 to +511 in
comma-separated NR1 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:IN
Terpolate {{0 | OFF}
| {1 | ON}} (see
page 1279)
:WGEN<w>:ARBitrary:IN
Terpolate? (see
page 1279)
{0 | 1}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:ST
ORe <source> (see
page 1280)
n/a <source> ::= {CHANnel<n> |
WMEMory<r> | FUNCtion<m> |
MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FREQuency
<frequency> (see
page 1281)
:WGEN<w>:FREQuency?
(see page 1281)
<frequency> ::= frequency in Hz
in NR3 format
<w> ::= 1 or 2 in NR1 format
