Keysight Technologies InfiniiVision MSO-X 4022A

192 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:WMEMory<r>:SAVE
<source> (see
page 1322)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
NOTE: Math functions whose x-axis
is not frequency can be saved as
reference waveforms.
:WMEMory<r>:SKEW
<skew> (see page 1323)
:WMEMory<r>:SKEW?
(see page 1323)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<skew> ::= time in seconds in NR3
format
:WMEMory<r>:YOFFset
<offset>[suffix] (see
page 1324)
:WMEMory<r>:YOFFset?
(see page 1324)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<offset> ::= vertical offset
value in NR3 format
[suffix] ::= {V | mV}
:WMEMory<r>:YRANge
<range>[suffix] (see
page 1325)
:WMEMory<r>:YRANge?
(see page 1325)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<range> ::= vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
:WMEMory<r>:YSCale
<scale>[suffix] (see
page 1326)
:WMEMory<r>:YSCale?
(see page 1326)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<scale> ::= vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
Table 73 :WMEMory<r> Commands Summary (continued)
Command Query Options and Query Returns
