6 Root (:) Commands
Introduction to
Root (:)
Commands
Root level commands control many of the basic operations of the instrument.
These commands are always recognized by the parser if they are prefixed with a
colon, regardless of current command tree position. After executing a root-level
command, the parser is positioned at the root of the command tree.
n/a :STATus? <display>
(see page 259)
{0 | 1}
<display> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion<m> | MATH<m> |
SBUS{1 | 2} | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
:STOP (see page 260) n/a n/a
n/a :TER? (see page 261) {0 | 1}
:VIEW <source> (see
page 262)
n/a <source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> | SBUS{1 |
2} | WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion<m> | MATH<m> |
SBUS{1 | 2} | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
Table 79 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
