Keysight InfiniiVision 4000 X-Series Oscilloscopes
Programmer's Guide
8 :BUS<n> Commands
Control all oscilloscope functions associated with buses made up of digital
channels. See "Introduction to :BUS<n> Commands" on page 280.
Table 91 :BUS<n> Commands Summary
Command Query Options and Query Returns
:BUS<n>:BIT<m> {{0 |
OFF} | {1 | ON}} (see
page 281)
:BUS<n>:BIT<m>? (see
page 281)
{0 | 1}
<n> ::= 1 or 2; an integer in NR1
format
<m> ::= 0-15; an integer in NR1
format
:BUS<n>:BITS
<channel_list>, {{0 |
OFF} | {1 | ON}} (see
page 282)
:BUS<n>:BITS? (see
page 282)
<channel_list>, {0 | 1}
<channel_list> ::= (@<m>,<m>:<m>
...) where "," is separator and
":" is range
<n> ::= 1 or 2; an integer in NR1
format
<m> ::= 0-15; an integer in NR1
format
:BUS<n>:CLEar (see
page 284)
n/a <n> ::= 1 or 2; an integer in NR1
format
:BUS<n>:DISPlay {{0 |
OFF} | {1 | ON}} (see
page 285)
:BUS<n>:DISPlay? (see
page 285)
{0 | 1}
<n> ::= 1 or 2; an integer in NR1
format
