352 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
14 :DIGital<d> Commands
Introduction to
:DIGital<d>
Commands
<d> ::= 0 to (# digital channels - 1) in NR1 format
The DIGital subsystem commands control the viewing, labeling, and positioning of
digital channels. They also control threshold settings for groups of digital
channels, or pods.
Reporting the Setup
Use :DIGital<d>? to query setup information for the DIGital subsystem.
Return Format
The following is a sample response from the :DIGital0? query. In this case, the
query was issued following a *RST command.
:DIG0:DISP 0;THR +1.40E+00;LAB 'D0';POS +0
These commands are only valid for the MSO models.
