56 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
1 What's New
Changed
Commands
:SAVE:RESults:FORMat:CURSo
r (see page 839)
Specifies whether cursor values will be included when analysis
results are saved.
:SAVE:RESults:FORMat:MASK
(see page 840)
Specifies whether mask statistics will be included when analysis
results are saved.
:SAVE:RESults:FORMat:MEASu
rement (see page 841)
Specifies whether measurement results will be included when
analysis results are saved.
:SAVE:RESults:FORMat:SEARc
h (see page 842)
Specifies whether found search event times will be included when
analysis results are saved.
:SAVE:RESults:FORMat:SEGMe
nted (see page 843)
Specifies whether segmented memory acquisition times will be
included when analysis results are saved.
:SEARch:PEAK Commands (see
page 1165)
Commands to set up searching for FFT peaks.
:SBUS<n>:CAN:COUNt:SPEC
(see page 883)
Returns the count for the number of Spec errors (Ack + Form +
Stuff + CRC errors).
:SBUS<n>:CAN:FDSPoint (see
page 887)
Sets the CAN FD sample point.
:SBUS<n>:CAN:SIGNal:FDBaud
rate (see page 892)
Sets the CAN FD baud rate.
:SBUS<n>:CAN:TRIGger:IDFilte
r (see page 897)
Specifies, in certain error and bit trigger modes, whether triggers
are filtered by CAN IDs.
:SBUS<n>:CAN:TRIGger:PATTer
n:DATA:DLC (see page 899)
Specifies the DLC value to be used in the CAN FD data trigger
mode.
:SBUS<n>:CAN:TRIGger:PATTer
n:DATA:STARt (see page 901)
Specifies the starting byte position for CAN FD data triggers.
:SBUS<n>:SENT Commands
(see page 1037)
Commands for using the SENT triggering and serial decode
feature.
:SEARch:SERial:SENT
Commands (see page 1228)
Commands for searching SENT serial decode events.
:WGEN<w>:TRACk:PHASe (see
page 1476)
Sets the phase relationship of a frequency-tracked waveform
generator output.
Command Description
Command Differences
:DEMO:FUNCtion (see
page 386)
The DCMotor, HARMonics, COUPling, CFD, and SENT functions
are now available with the educator's kit.
