What's New in Version 3.20
New features in version 3.20 of the InfiniiVision 4000 X-Series oscilloscope
software are:
• Being able to load CAN symbolic data from a *.dbc file into the oscilloscope,
display it in the decode, and use it to set up triggers and protocol decode
searches.
• LIN triggering and decode updates.
More detailed descriptions of the new and changed commands appear below.
New Commands
Command Description
:COMPliance:USB:HUBS (see
page 369)
Specifies the number of internal hubs between the host and the
test point.
:MARKer:DYDX? (see
page 530)
Returns the cursor ∆Y/∆X value.
:MEASure:NDUTy (see
page 596)
Negative duty cycle measurement.
:RECall:DBC[:STARt] (see
page 813)
Loads a CAN DBC (communication database) symbolic data file
into the oscilloscope.
:SBUS<n>:CAN:DISPlay (see
page 886)
Specifies whether symbolic values (from a loaded DBC file) or
hexadecimal values are displayed in the decode waveform and the
Lister window
:SBUS<n>:CAN:TRIGger:SYMB
olic:MESSage (see page 904)
Specifies the message to trigger on when CAN symbolic data has
been loaded (recalled) into the oscilloscope and the CAN trigger
mode is set to MESSage or MSIGnal.
:SBUS<n>:CAN:TRIGger:SYMB
olic:SIGNal (see page 905)
Specifies signal to trigger on when CAN symbolic data has been
loaded (recalled) into the oscilloscope and the CAN trigger mode
is set to MSIGnal.
:SBUS<n>:CAN:TRIGger:SYMB
olic:VALue (see page 906)
Specifies signal value to trigger on when CAN symbolic data has
been loaded (recalled) into the oscilloscope and the CAN trigger
mode is set to MSIGnal.
:SEARch:EVENt (see
page 1152)
Lets you navigate to one of the found search events.
:SEARch:SERial:CAN:SYMBolic:
MESSage (see page 1193)
Specifies the message to search for when CAN symbolic data has
been loaded (recalled) into the oscilloscope and the CAN serial
search mode is set to MESSage or MSIGnal.
