Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 89
Table 3 Root (:) Commands Summary
Command Query Options and Query Returns
:ACTivity (see
page 227)
:ACTivity? (see
page 227)
<return value> ::=
<edges>,<levels>
<edges> ::= presence of edges
(32-bit integer in NR1 format)
<levels> ::= logical highs or
lows (32-bit integer in NR1
format)
n/a :AER? (see page 228) {0 | 1}; an integer in NR1 format
:AUToscale
[<source>[,..,<source
>]] (see page 229)
n/a <source> ::= CHANnel<n> for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d> | POD1 | POD2} for MSO
models
<source> can be repeated up to 5
times
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:AUToscale:AMODE
<value> (see page 231)
:AUToscale:AMODE?
(see page 231)
<value> ::= {NORMal | CURRent}}
:AUToscale:CHANnels
<value> (see page 232)
:AUToscale:CHANnels?
(see page 232)
<value> ::= {ALL | DISPlayed}}
:AUToscale:FDEBug {{0
| OFF} | {1 | ON}}
(see page 233)
:AUToscale:FDEBug?
(see page 233)
{0 | 1}
:BLANk [<source>]
(see page 234)
n/a <source> ::= {CHANnel<n>} |
FUNCtion<m> | MATH<m> | SBUS{1 |
2} | WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion<m> | MATH<m> |
SBUS{1 | 2} | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
