:SBUS<n>:SENT:SIGNal<
s>:ORDer <order> (see
page 914)
:SBUS<n>:SENT:SIGNal<
s>:ORDer? (see
page 914)
<s> ::= 1-6, in NR1 format.
<order> ::= {MSNFirst | LSNFirst}
:SBUS<n>:SENT:SIGNal<
s>:STARt <position>
(see page 916)
:SBUS<n>:SENT:SIGNal<
s>:STARt? (see
page 916)
<s> ::= 1-6, in NR1 format.
<position> ::= from 0-23, in NR1
format.
:SBUS<n>:SENT:SOURce
<source> (see
page 918)
:SBUS<n>:SENT:SOURce?
(see page 918)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SENT:TOLeran
ce <percent> (see
page 920)
:SBUS<n>:SENT:TOLeran
ce? (see page 920)
<percent> ::= from 3-30, in NR1
format.
:SBUS<n>:SENT:TRIGger
<mode> (see page 921)
:SBUS<n>:SENT:TRIGger
? (see page 921)
<mode> ::= {SFCMessage |
SSCMessage | FCData | SCMid |
SCData | FCCerror | SCCerror |
CRCerror | TOLerror | PPERror |
SSPerror}
:SBUS<n>:SENT:TRIGger
:FAST:DATA <string>
(see page 923)
:SBUS<n>:SENT:TRIGger
:FAST:DATA? (see
page 923)
<string> ::= "nnnn..." where n
::= {0 | 1 | X}
<string> ::= "0xn..." where n ::=
{0,..,9 | A,..,F | X | $}
:SBUS<n>:SENT:TRIGger
:SLOW:DATA <data>
(see page 924)
:SBUS<n>:SENT:TRIGger
:SLOW:DATA? (see
page 924)
<data> ::= when ILENgth = SHORt,
from -1 (don't care) to 65535, in
NR1 format.
<data> ::= when ILENgth = LONG,
from -1 (don't care) to 4095, in
NR1 format.
:SBUS<n>:SENT:TRIGger
:SLOW:ID <id> (see
page 926)
:SBUS<n>:SENT:TRIGger
:SLOW:ID? (see
page 926)
<id> ::= when ILENgth = SHORt,
from -1 (don't care) to 15, in
NR1 format.
<id> ::= when ILENgth = LONG,
from -1 (don't care) to 255, in
NR1 format.
Table 121 :SBUS<n>:SENT Commands Summary (continued)
Command Query Options and Query Returns
