11 STATus Subsystem
482 N1911A/1912A P-Series Power Meters Programming Guide
STATus:OPERation:ULFail[:SUMMary]
The operation status upper limit fail summary register set contains information on
the upper limit fail status of the power meter.
The following bits in these registers are used by the power meter:
The appropriate bits are set if a channel upper limit test fails or a window upper
limit test fails.
These bits are cleared if a measurement is made and the test is enabled and
passes.
Syntax
Bit Number Decimal Weight Definition
0-Not used
1 2 Channel A ULFail Status
2 4 Channel B ULFail Status (N1912A only)
3 8 Upper window ULFail Status
4 16 Lower window ULFail Status
5 32 Upper window lower measurement LLFail Status
6 64 Lower window lower measurement LLFail Status
7-15 - Not used
