5 DISPlay Subsystem
254 N1911A/1912A P-Series Power Meters Programming Guide
DISPlay[:WINDow[1]|2]:SELect[1]|2
This command is used to select a specific measurement within a specific window.
If the second numeric value is not sent, the upper measurement of the relevant
window is selected. This command is used to specify which measurement is used
for the analog, trace, or single numeric display.
Syntax
Example
Reset Condition
On reset, the upper window upper measurement is selected.
Query
DISPlay[:WINDow[1]|2]:SELect[1]|2?
The query enters a 1 or 0 into the output buffer indicating whether the window
specified is currently selected.
– 1 is returned if the specified window is selected
– 0 is returned if the specified window is not selected
DISP:WIND2:SEL1 This command selects the upper
measurement in the lower window.
