Keysight N1911A

SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 539
Table 12-6 EDGE: Power Meter Presets: Window/Measurement Settings
[SENSe[1]]|SENS2:AVER:SDET 1 Step detection enabled
Trace setup
SENSe[1]|2:TRAC:LIM:UPP +20 dBm Maximum power
SENSe[1]|2:TRAC:LIM:LOW –35 dBm Minimum power
[SENS[1]]|SENS2:TRAC:OFFS
:TIME <numeric_value>
–40 µs Delay between delayed trigger point and
the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
700 µs Length of the trace
Command Setting Comments
NOTE
The Range setting in Table 12-5 is only applicable for E-Series power sensor and
N8480 Series power sensor (excluding Option CFT)
Function
Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
Lower window Dual numeric See Table 12-7
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
