Keysight N1911A

12 SYSTem Subsystem
558 N1911A/1912A P-Series Power Meters Programming Guide
[a] The Range setting in Table 12-20 is only applicable for E-Series power sensor and N8480 Series power sensor (excluding Option CFT).
Table 12-21 MPCA: Power Meter Presets: Window/Measurement Settings
TRIG[:SEQ[1]|2]:SOUR INT1 Trigger source set up and acquisition
mode continuous triggering
INIT:CONT ON
TRIG[:SEQ]:LEV:AUTO OFF Enable automatic setting of the trigger
level
TRIG[:SEQ]:LEV -15 dBm Power level
TRIG[:SEQ]:SLOP POS Trigger event recognized on the rising
edge of a signal
TRIG[:SEQ]:DEL 0 s Delay between recognition of trigger event
and start of a measurement
TRIG[:SEQ]:HOLD MIN Trigger holdoff
Range
[a]
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 0 Step detection disabled
Command Setting Comments
Function Setting
Single Channel Dual Channel
Display setup
Upper window UU single numeric UU single numeric
Lower window Dual numeric See Table 12-22
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Upper window/lower measurement (UL)
