Sensor
Different measurement rates are achievable depending on the sensor type being
used, as shown in Table 1-4:
Table 1-4 Model of Sensor and Measurement Rates
Trigger Mode
The power meter has a very flexible triggering system. For simplicity, it can be
described as having three modes:
– Free Run: When a channel is in Free Run, it continuously takes measurements
on this channel. A channel is in free run when INITiate:CONTinuous is set to
ON and TRIGger:SOURce is set to IMMediate.
– Triggered Free Run: When a channel is in Triggered Free Run Continuous
Trigger, it takes a new measurement each time a trigger event is detected.
A channel is in Triggered Free Run Continuous Trigger when
INITiate:CONTinuous is set to ON and TRIGger:SOURce is not set to
IMMediate.
Sensor Measurement Rate
NORMal DOUBle FAST
8480 Series and N8480 Series 20 reading/s 40 reading/s NA
E-Series E4410 and E9300
50 ms
20 reading/s
25 ms
40 reading/s
Up to 400
E-Series E9320,
AVERage only mode
50 ms
20 reading/s
25 ms
40 reading/s
Up to 400
E-Series E9320,
NORMal mode
50 ms
20 reading/s
25 ms
40 reading/s
Up to 1000
P-Series
50 ms
20 reading/s
25 ms
40 reading/s
Up to 1500
