Keysight N1911A

12 SYSTem Subsystem
606 N1911A/1912A P-Series Power Meters Programming Guide
[a] The Range setting in Table 12-62 is only applicable for E-Series power sensor and N8480 Series power sensor (excluding Option CFT).
Table 12-63 LTE: Power Meter Presets: Window/Measurement Settings
TRIG[:SEQ]:HOLD 4 ms Trigger holdoff
Range
[a]
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 0 Step detection is disabled
Trace setup
[SENS[1]]|SENS2:TRAC:OFFS
:TIME <numeric_value>
–0.2 ms Delay between delayed trigger point and
the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
11.0
ms
Length of the trace
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
Lower window Dual numeric See Table 12-64
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Command Setting Comments
