SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 557
MCPA
The following table shows the power meter presets when <character_data> is set
to MCPa. Commands not listed are preset according to their DEFault values (for
further information refer to Table 12-1).
Table 12-20 MPCA: Power Meter Presets
Lower window/lower measurement (LL)
Feed Gate 1 primary channel1
Secondary channel
[a]
Gate1 secondary
channel
[a]
(Channel B)
Measurement Peak Avg Avg
[a] For further information refer to “Primary and Secondary Channels” on page 527.
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320 Sensor
Command Setting Comments
Frequency
[SENS[1]]|SENS2:FREQ[:CW|:FIX] +1900.000 MHz Frequency setting
Sensor measurement mode
[SENS[1]]|SENS2:DET:FUNC NORM Measurement mode
Sensor video bandwidth setup
[SENS[1]]|SENS2:BAND|BWID:VID E9321A/25A: DEF
E9322A/26A: DEF
E9323A/27A: DEF
N1921/2A: HIGH
Sensor video bandwidth
Gate Setup
[SENS[1]]|SENS2:SWE[1]|2|3|4
:OFF:TIME
Gate 1: 0 s
Gates 2 - 4: 0
Delay between trigger point and time
gated period.
[SENS[1]]|SENS2:SWE[1]|2|3|4
:TIME
Gate 1: 10 ms
Gates 2 - 4: 0
Length of time gated period for time gated
measurements.
Trigger setup
