12 SYSTem Subsystem
582 N1911A/1912A P-Series Power Meters Programming Guide
Table 12-42 NADC: Power Meter Presets: Window/Measurement Settings
Function
Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
[a] For further information refer to “Primary and Secondary Channels” on page 527.
Lower window Dual numeric See Table 12-43
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Lower window/lower measurement (LL)
Feed Gate 2 Channel A See Table 12-43
Measurement Avg See Table 12-43
