RADAR
The following table shows the power meter presets when <character_data> is set
to RADar. Commands not listed are preset according to their DEFault values (for
further information refer to Table 12-1).
Table 12-23 RADAR: Power Meter Presets
Command Setting Comments
Frequency
[SENS[1]]|SENS2:FREQ[:CW|:FIX] +10.000 GHz Frequency setting
Sensor measurement mode
[SENS[1]]|SENS2:DET:FUNC NORM Measurement mode
Sensor video bandwidth setup
[SENS[1]]|SENS2:BAND|BWID:VID E9321A/25A: DEF
E9322A/26A: DEF
E9323A/27A: OFF
N1921/2A: OFF
Sensor video bandwidth
Gate Setup
[SENS[1]]|SENS2:SWE[1]|2|3|4
:OFF:TIME
Gate 1: 0
Gate 2: 0
Gate 3: 750 ns
Gate 4: 0
Delay between trigger point and time
gated period.
[SENS[1]]|SENS2:SWE[1]|2|3|4
:TIME
Gate 1: 1.0 µs
Gate 2: 250 ns
Gate 3: 250 ns
Gate 4: 0
Length of time gated period for time gated
measurements.
Trigger setup
TRIG[:SEQ[1]|2]:SOUR INT1 Trigger source set up and acquisition
mode continuous triggering
INIT:CONT ON
TRIG[:SEQ]:LEV:AUTO ON Disable automatic setting of the trigger
level
TRIG[:SEQ]:LEV AUTO Automatic Power level
TRIG[:SEQ]:SLOP POS Trigger event recognized on the rising
edge of a signal
