12 SYSTem Subsystem
536 N1911A/1912A P-Series Power Meters Programming Guide
Table 12-3 GSM900: Power Meter Presets: Window/Measurement Settings
Table 12-4 GSM900: Power Meter Presets For Secondary Channel Sensors
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
[a] For further information refer to “Primary and Secondary Channels” on page 527.
Lower window LU single numeric See Table 12-4
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Lower window/lower measurement (LL)
Feed DEF See Table 12-4
Measurement DEF See Table 12-4
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320 Sensor
Display setup
Lower window LU single numeric Dual numeric Dual numeric
