Table 12-28 802.11a and HiperLan2: Power Meter Presets For Secondary Channel Sensors
[a] For further information refer to “Primary and Secondary Channels” on page 527.
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320 Sensor P-Series and E9320 Sensor
Display setup
Upper window UU Single numeric Dual numeric Dual numeric
Lower window Dual numeric Dual numeric Dual numeric
Upper window/lower measurement (UL)
Feed DEF
Gate 1 primary channel
[a]
[a] For further information refer to “Primary and Secondary Channels” on page 527.
Gate1 primary channel
[a]
(Channel A)
Measurement DEF Peak Peak
Lower window/upper measurement (LU)
Feed
Gate 1 primary channel
[a]
Gate 1 primary channel
[a]
Gate 1 secondary channel
[a]
(Channel B)
Measurement Peak Pk-to-Avg Avg
Lower window/lower measurement (LL)
Feed
Gate 1 primary channel
[a]
Secondary channel
[a]
Gate 1 secondary channel
[a]
(Channel B)
Measurement Pk-to-Avg Avg Pk-to-Avg
