SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 589
[a] The Range setting in Table 12-47 is only applicable for E-Series power sensor and N8480 Series power sensor (excluding Option CFT).
Table 12-48 DVB: Power Meter Presets: Window/Measurement Settings
TRIG[:SEQ]:HOLD 20 ms Trigger holdoff
Range
[a]
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 1 Step detection enabled
Function Setting
Single Channel Dual Channel
Display setup
Upper window UU single numeric See Table 12-49
Lower window Dual numeric See Table 12-49
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Upper window/lower measurement (UL)
Feed DEF See Table 12-49
Measurement DEF See Table 12-49
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-49
Measurement Pk-to-Avg See Table 12-49
Lower window/lower measurement (LL)
Command Setting Comments
