Keysight N1911A

12 SYSTem Subsystem
538 N1911A/1912A P-Series Power Meters Programming Guide
Sensor measurement mode
[SENS[1]]|SENS2:DET:FUNC NORM Measurement mode
Sensor video bandwidth setup
[SENS[1]]|SENS2:BAND|BWID:VID E9321A/25A: HIGH
E9322A/26A: MED
E9323A/27A: LOW
N1921/2A: LOW
Sensor video bandwidth
Gate Setup
[SENS[1]]|SENS2:SWE[1]|2|3|4
:OFF:TIME
Gate 1: 20 µs
Gates 2 - 4: 0
Delay between trigger point and time gated
period.
[SENS[1]]|SENS2:SWE[1]|2|3|4
:TIME
Gate 1: 520 µs
Gates 2 - 4: 0
Length of time gated period for time gated
measurements.
Trigger setup
TRIG[:SEQ[1]|2]:SOUR INT1 Trigger source set up and acquisition mode
continuous triggering
INIT:CONT ON
TRIG[:SEQ]:LEV:AUTO OFF Disable automatic setting of the trigger
level
TRIG[:SEQ]:LEV –15 dBm Power level
TRIG[:SEQ]:SLOP POS Trigger event recognized on the rising edge
of a signal
TRIG[:SEQ]:DEL 0 s Delay between recognition of trigger event
and start of a measurement
TRIG[:SEQ]:HOLD 4275 µs Trigger holdoff
TRIG[:SEQ]:HYST 3 dB Hysteresis
Range
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Averaging
[SENSe[1]]|SENSe2:AVER[:STATe] ON Averaging On
[SENSe[1]]|SENSe2:AVER:COUN 64 Averaging set to 64
Step detection
Command Setting Comments
