TRACe Subsystem 13
N1911A/1912A P-Series Power Meters Programming Guide 615
Parameters
Example
Error Messages
If TRAC:STAT is off, the error –221, “Settings Conflict” occurs.
Item Description/Default Range of Values
character_data – HRESolution: high resolution. The complete capture buffer at the internal
sample rate. The number of points in this trace is not fixed, as it is affected by the
SENS:TRACe:TIMe setting.
– MRESolution: medium resolution. A subset of the capture buffer - the buffer
contents are decimated
to 1000 data points.
– LRESolution: low resolution. A subset of the capture buffer - the buffer
contents are decimated to provide 230 data points. This is the same number of
data points as the power meter uses to display the trace on the front panel. Hence,
the LRES command can be used to replicate the power meter’s display.
HRES
MRES
LRES
TRAC:DATA? HRES This command returns the trace data for
Channel A at high resolution.
The TRIG:SOUR must be set to something other than IMM, and INIT:CONT must
be set to off.
