Operation
260
Pos: 55.168.37 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Verlust Folienr olle @ 75\mod_13093263043 96_78.docx @ 661811 @ @ 1
COM00213
5
7
8
9
Fig. 200
DANGER! – Loss of the Sheet Roll!
Injuries or damage to the machine.
• After insertion of the sheet roll (2) secure it immediately by hooking the tension spring (5)
• Check if the locking bolt (8) is pressed tight to the flat iron (9) Only this guarantees the tight
seating of the sheet roll.
After installing the sheet roll, make certain that
• the wrapping arm can rotate freely in all positions,
• the pre-stretching unit is lubricated well
Pos: 55.168.38 /Layout Module /------ ---------Seitenumbruc h---------------- @ 0\mod_1196175311226_0. docx @ 4165 @ @ 1
To Next Page
