Oset stacker handle cover removal
1
R
emove
the left and right covers. Go to
“Oset
stacker left cover
removal” on page
449
and
“Oset
stacker right cover removal” on
page
448
.
2
R
emove the screw (A) on each side
of the handle
cover
.
A
A
3
Lift up and to the
rear to re
move the
cover
.
7462
R
epair information
451
450
452
