4 Remove the two screws (A) securing the two paddle drive motor assemblies.
A
5 Remove the paddle drive motor assembly.
Sensor (MFP stapler assembly media stack) removal
1 Remove the top cover. Go to “MFP stapler assembly top cover removal” on page 487.
2 Disconnect the harness to the sensor (media stack).
7462
Repair information
496
