REV 0, June 2005Page 130
Operation Manual SUPREMA
5. Installation
• Set on rack 2
• Bitrate: 50 kB
• Switch on the CAN-terminating resistor at MIB 20
Parameter Setting for CAN Bus A
Net 0 is the Central Rack
To reduce the data overflow at the CAN bus, the CAN bridge is provided with a filter which only
lets the data required pass through to NET 1.
Filter for NET 0 after NET 1:
B0:6 {Bit rate = 125kB}
I0:0 I1:0 {START/STOP}
I0:80 I1:80 {Sync Byte}
I0:100 I1:100 {Time stamp}
I0:614 I1:614 {SDO tx MDA (SAT1)}
I0:714 I1:714 {Nodegard for MDA (SAT1)}
I0:21E I1:21E {Data for MGO (SAT1)}
I0:61E I1:61E {SDO tx MGO (SAT1)}
I0:71E I1:71E {Nodegard for MGO (SAT1)}
Net 1 are the satellites
Filter for NET1 to NET0:
B1:9 {Bit rate = 50kb}
M1:0:0xxxxxxxxxxxxxxxxxxxxxxxxxxxxx {Mask for NET1 to NET0}
With help of a text editor, a *.txt file is generated, which only contains the data required:
B0:6
I0:0 I1:0
I0:80 I1:80
I0:100 I1:100
I0:614 I1:614
I0:714 I1:714
I0:21E I1:21E
I0:61E I1:61E
I0:71E I1:71E
B1:9
M1:0:0xxxxxxxxxxxxxxxxxxxxxxxxxxxxx
