Chapter 8: LPC13xx Pin configuration
8.4.2 HVQFN33 packages
Table 145. LPC1311/13/42/43 HVQFN33 pin description table
Symbol Pin Start
logic
input
Type Reset
state
[1]
Description
RESET
/PIO0_0 2
[2]
yes I I; PU RESETExternal reset input with 20 ns glitch filter. A LOW-going pulse
as short as 50 ns on this pin resets the device, causing I/O ports and
peripherals to take on their default states, and processor execution to
begin at address 0.
I/O - PIO0_0 — General purpose digital input/output pin with 10 ns glitch filter.
PIO0_1/CLKOUT/
CT32B0_MAT2/
USB_FTOGGLE
3
[3]
yes I/O I; PU PIO0_1 — General purpose digital input/output pin. A LOW level on this
pin during reset starts the ISP command handler or the USB device
enumeration (USB on LPC1342/43 only, see description of PIO0_3).
O- CLKOUT — Clock out pin.
O- CT32B0_MAT2 — Match output 2 for 32-bit timer 0.
O- USB_FTOGGLE — USB 1 ms Start-of-Frame signal (LPC1342/43 only).
PIO0_2/SSEL0/
CT16B0_CAP0
8
[3]
yes I/O I; PU PIO0_2 — General purpose digital input/output pin.
I/O - SSEL0 — Slave select for SSP0.
I- CT16B0_CAP0 — Capture input 0 for 16-bit timer 0.
PIO0_3/
USB_VBUS
9
[3]
yes I/O I; PU PIO0_3 — General purpose digital input/output pin. LPC1342/43 only: A
LOW level on this pin during reset starts the ISP command handler, a
HIGH level starts the USB device enumeration.
I- USB_VBUS — Monitors the presence of USB bus power (LPC1342/43
only).
PIO0_4/SCL 10
[4]
yes I/O I; IA PIO0_4 — General purpose digital input/output pin (open-drain).
I/O - SCL — I
2
C-bus clock input/output (open-drain). High-current sink only if
I
2
C Fast-mode Plus is selected in the I/O configuration register.
PIO0_5/SDA 11
[4]
yes I/O I; IA PIO0_5 — General purpose digital input/output pin (open-drain).
I/O - SDA — I
2
C-bus data input/output (open-drain). High-current sink only if
I
2
C Fast-mode Plus is selected in the I/O configuration register.
PIO0_6/
USB_CONNECT
/
SCK0
15
[3]
yes I/O I; PU PIO0_6 — General purpose digital input/output pin.
O- USB_CONNECT
Signal used to switch an external 1.5 k resistor
under software control. Used with the SoftConnect USB feature
(LPC1342/43 only).
I/O - SCK0 — Serial clock for SSP0.
PIO0_7/CTS
16
[3]
yes I/O I; PU PIO0_7 — General purpose digital input/output pin (high-current output
driver).
I- CTS
Clear To Send input for UART.
PIO0_8/MISO0/
CT16B0_MAT0
17
[3]
yes I/O I; PU PIO0_8 — General purpose digital input/output pin.
I/O - MISO0 — Master In Slave Out for SSP0.
O- CT16B0_MAT0 — Match output 0 for 16-bit timer 0.
PIO0_9/MOSI0/
CT16B0_MAT1/
SWO
18
[3]
yes I/O I; PU PIO0_9 — General purpose digital input/output pin.
I/O - MOSI0 — Master Out Slave In for SSP0.
O- CT16B0_MAT1 — Match output 1 for 16-bit timer 0.
O- SWO — Serial wire trace output.
