UM10375 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 3 — 14 June 2011 158 of 368
NXP Semiconductors
UM10375
Chapter 10: LPC13xx USB device controller
10.11.8 Get Device Status (Command: 0xFE, Data: read 1 byte)
The Get Device Status command returns the Device Status Register. Reading the device
status returns 1 byte of data. The bit field definition is same as the Set Device Status
Register as shown in Table 181
.
Remark: To ensure correct operation, the DEV_STAT bit of USBDevIntSt must be cleared
before executing the Get Device Status command.
2 SUS Suspend: The Suspend bit represents the current suspend state.
When the device is suspended (SUS = 1) and the CPU writes a 0
into it, the device will generate a remote wake-up. This will only
happen when the device is connected (CON = 1). When the
device is not connected or not suspended, writing a 0 has no
effect. Writing a 1 to this bit has no effect.
0
0 This bit is reset to 0 on any activity.
1 This bit is set to 1 when the device hasn’t seen any activity on its
upstream port for more than 3 ms.
3 SUS_CH Suspend (SUS) bit change indicator. The SUS bit can toggle
because:
• The device goes into the suspended state.
• The device is disconnected.
• The device receives resume signalling on its upstream port.
This bit is cleared when read.
0
0 SUS bit not changed.
1 SUS bit changed. At the same time a DEV_STAT interrupt is
generated.
4 RST Bus Reset bit. On a bus reset, the device will automatically go to
the default state. In the default state:
• Device is unconfigured.
• Will respond to address 0.
• Control endpoint will be in the Stalled state.
• Data toggling is reset for all endpoints.
• All buffers are cleared.
• There is no change to the endpoint interrupt status.
• DEV_STAT interrupt is generated.
Note: Bus resets are ignored when the device is not connected
(CON=0).
0
0 This bit is cleared when read.
1 This bit is set when the device receives a bus reset. A DEV_STAT
interrupt is generated.
7:5 - Reserved, user software should not write ones to reserved bits.
The value read from a reserved bit is not defined.
NA
Table 181. Set Device Status command description
Bit Symbol Value Description Reset
value
