Chapter 7: LPC13xx I/O configuration
The pin functions selectable in each IOCON register are listed in order (function 0/function
1/function 2/...) in the description column in Table 95
.
Remark: The IOCON registers are listed in order of their memory locations in Table 95
which correspond to the order of their physical pin numbers in the LQFP48 package
starting at the upper left corner with pin 1 (PIO2_6). See Table 96
for a listing of IOCON
registers ordered by port number.
Table 95. Register overview: I/O configuration block (base address 0x4004 4000)
Name Access Address
offset
Description Reset
value
IOCON_PIO2_6 R/W 0x000 I/O configuration for pin PIO2_6 0xD0
- R/W 0x004 Reserved -
IOCON_PIO2_0 R/W 0x008 I/O configuration for pin PIO2_0/DTR
/SSEL1 0xD0
IOCON_RESET_PIO0_0 R/W 0x00C I/O configuration for pin RESET
/PIO0_0 0xD0
IOCON_PIO0_1 R/W 0x010 I/O configuration for pin PIO0_1/CLKOUT/
CT32B0_MAT2/USB_FTOGGLE
0xD0
IOCON_PIO1_8 R/W 0x014 I/O configuration for pin PIO1_8/CT16B1_CAP0 0xD0
- R/W 0x018 Reserved -
IOCON_PIO0_2 R/W 0x01C I/O configuration for pin PIO0_2/SSEL0/
CT16B0_CAP0
0xD0
IOCON_PIO2_7 R/W 0x020 I/O configuration for pin PIO2_7 0xD0
IOCON_PIO2_8 R/W 0x024 I/O configuration for pin PIO2_8 0xD0
IOCON_PIO2_1 R/W 0x028 I/O configuration for pin PIO2_1/DSR
/SCK1 0xD0
IOCON_PIO0_3 R/W 0x02C I/O configuration for pin PIO0_3/USB_VBUS 0xD0
IOCON_PIO0_4 R/W 0x030 I/O configuration for pin PIO0_4/SCL 0x00
IOCON_PIO0_5 R/W 0x034 I/O configuration for pin PIO0_5/SDA 0x00
IOCON_PIO1_9 R/W 0x038 I/O configuration for pin PIO1_9/CT16B1_MAT0 0xD0
IOCON_PIO3_4 R/W 0x03C I/O configuration for pin PIO3_4 0xD0
IOCON_PIO2_4 R/W 0x040 I/O configuration for pin PIO2_4 0xD0
IOCON_PIO2_5 R/W 0x044 I/O configuration for pin PIO2_5 0xD0
IOCON_PIO3_5 R/W 0x048 I/O configuration for pin PIO3_5 0xD0
IOCON_PIO0_6 R/W 0x04C I/O configuration for pin PIO0_6/USB_CONNECT
/SCK 0xD0
IOCON_PIO0_7 R/W 0x050 I/O configuration for pin PIO0_7/CTS
0xD0
IOCON_PIO2_9 R/W 0x054 I/O configuration for pin PIO2_9 0xD0
IOCON_PIO2_10 R/W 0x058 I/O configuration for pin PIO2_10 0xD0
IOCON_PIO2_2 R/W 0x05C I/O configuration for pin PIO2_2/DCD
/MISO1 0xD0
IOCON_PIO0_8 R/W 0x060 I/O configuration for pin PIO0_8/MISO0/CT16B0_MAT0 0xD0
IOCON_PIO0_9 R/W 0x064 I/O configuration for pin PIO0_9/MOSI0/
CT16B0_MAT1/SWO
0xD0
IOCON_SWCLK_PIO0_10 R/W 0x068 I/O configuration for pin SWCLK/PIO0_10/
SCK/CT16B0_MAT2
0xD0
IOCON_PIO1_10 R/W 0x06C I/O configuration for pin PIO1_10/AD6/
CT16B1_MAT1
0xD0
IOCON_PIO2_11 R/W 0x070 I/O configuration for pin PIO2_11/SCK 0xD0
IOCON_R_PIO0_11 R/W 0x074 I/O configuration for pin R/PIO0_11/AD0/CT32B0_MAT3 0xD0
