UM10375 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 3 — 14 June 2011 341 of 368
NXP Semiconductors
UM10375
Chapter 21: LPC13xx Flash memory programming firmware
21.14.9 ReadUID
21.14.10 IAP Status Codes
21.15 Debug notes
21.15.1 Comparing flash images
Depending on the debugger used and the IDE debug settings, the memory that is visible
when the debugger connects might be the boot ROM, the internal SRAM, or the flash. To
help determine which memory is present in the current debug environment, check the
value contained at flash address 0x0000 0004. This address contains the entry point to
the code in the ARM Cortex-M3 vector table, which is the bottom of the boot ROM, the
internal SRAM, or the flash memory respectively.
Table 343. IAP ReadUID command
Command Compare
Input Command code: 58 (decimal)
Return Code CMD_SUCCESS
Result Result0: The first 32-bit word (at the lowest address).
Result1: The second 32-bit word.
Result2: The third 32-bit word.
Result3: The fourth 32-bit word.
Description This command is used to read the unique ID.
Table 344. IAP Status Codes Summary
Status
Code
Mnemonic Description
0 CMD_SUCCESS Command is executed successfully.
1 INVALID_COMMAND Invalid command.
2 SRC_ADDR_ERROR Source address is not on a word boundary.
3 DST_ADDR_ERROR Destination address is not on a correct boundary.
4 SRC_ADDR_NOT_MAPPED Source address is not mapped in the memory map.
Count value is taken in to consideration where
applicable.
5 DST_ADDR_NOT_MAPPED Destination address is not mapped in the memory
map. Count value is taken in to consideration where
applicable.
6 COUNT_ERROR Byte count is not multiple of 4 or is not a permitted
value.
7 INVALID_SECTOR Sector number is invalid.
8 SECTOR_NOT_BLANK Sector is not blank.
9 SECTOR_NOT_PREPARED_
FOR_WRITE_OPERATION
Command to prepare sector for write operation was
not executed.
10 COMPARE_ERROR Source and destination data is not same.
11 BUSY flash programming hardware interface is busy.
