21.1 How to read this chapter
See Table 310 for different flash configurations and functionality. The LPC131x parts do
not have an USB interface and only the UART ISP option is supported.
Remark: In addition to the ISP and IAP commands, a register can be accessed in the
flash controller block to configure flash memory access times, see Section 21.16.1
.
21.2 Bootloader
The bootloader controls initial operation after reset and also provides the means to
program the flash memory. This could be initial programming of a blank device, erasure
and re-programming of a previously programmed device, or programming of the flash
memory by the application program in a running system.
The bootloader version can be read by ISP/IAP calls (see Section 21.13.12
or
Section 21.14.6
) and is part of the chip marking for some LPC13xx parts (see Table 311).
[1] Typical LPC134x devices have the following top-side marking:
LPC1343x
xxxxxxx
xxYYWW<bootloader version>R[x]
UM10375
Chapter 21: LPC13xx Flash memory programming firmware
Rev. 3 — 14 June 2011 User manual
Table 310. LPC13xx flash configurations
Type number Flash ISP via USB ISP via UART
LPC1311FHN33 8 kB no yes
LPC1313FBD48 32 kB no yes
LPC1313FHN33 32 kB no yes
LPC1342FHN33 16 kB yes yes
LPC1342FBD48 16 kB yes yes
LPC1343FBD48 32 kB yes yes
LPC1343FHN33 32 kB yes yes
LPC1311FHN33/01 8 kB no yes
LPC1313FHN33/01 32 kB no yes
LPC1313FBD48/01 32 kB no yes
Table 311. Bootloader versions
Part Bootloader
version read by
ISP/IAP
Top-side marking
[1]
Notes
LPC1311 5.1 no marking -
LPC1313 5.1 no marking -
LPC1342 5.2 1 See Section 21.2.1
.
LPC1343 5.2 1 See Section 21.2.1
.
