UM10375 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 3 — 14 June 2011 47 of 368
NXP Semiconductors
UM10375
Chapter 3: LPC13xx System configuration
3.10.2 Start logic
The Deep-sleep mode is exited when the start logic indicates an interrupt to the ARM
core. The various port pins (see Table 6
) are connected to the start logic and serve as
wake-up pins. The user must program the start logic registers for each input to set the
appropriate edge polarity for the corresponding wake-up event. Furthermore, the
interrupts corresponding to each input must be enabled in the NVIC. Interrupts 0 to 39 in
the NVIC correspond to 40 PIO pins (see Section 3.5.37
and Section 3.5.41).
The start logic does not require a clock to run because it uses the input signals on the
enabled pins to generate a clock edge when enabled. Therefore, the start logic signals
should be reset (see Table 46
and Table 50) before use.
The start logic can also be used in Active mode to provide a vectored interrupt using the
LPC13xx’s input pins.
3.10.3 Using the general purpose counter/timers to create a self-wake-up
event
If enabled in Deep-sleep mode through the SYSAHBCLKCFG register, the counter/timers
can count clock cycles of the watchdog oscillator and create a match event when the
number of cycles equals a preset match value. The match event causes the
corresponding match output pin to go HIGH, LOW, or toggle. The state of the match
output pin is also monitored by the start logic and can trigger a wake-up interrupt if that pin
is enabled in the NVIC and the start logic trigger is configured accordingly in the start logic
edge control register (see Table 44
and Table 48).
The following steps must be performed to configure the counter/timer and create a timed
Deep-sleep self-wake-up event:
1. Configure the port pin as match output in the IOCONFIG block. All pins with a match
function are also inputs to the start logic.
2. In the corresponding counter/timer, set the match value, and configure the match
output for the selected pin.
3. Select the watchdog oscillator to run in Deep-sleep mode in the PDSLEEPCFG
register.
4. Switch the clock source to the watchdog oscillator in the MAINCLKSEL register
(Table 22
) and ensure the watchdog oscillator is powered in the PDRUNCFG register.
5. Enable the pin, configure its edge detect function, and reset the start logic in the start
logic registers (Table 46
to Table 50), and enable the interrupt in the NVIC.
6. Disable all other peripherals in the SYSAHBCLKCTRL register.
7. Ensure that the DPDEN bit in the PCON register is set to zero (Table 61
).
8. Write one to the SLEEPDEEP bit in the ARM Cortex-M3 SCR register.
9. Start the counter/timer.
10. Use the ARM WFI instruction to enter Deep-sleep mode.
3.11 PLL (System PLL and USB PLL) functional description
The LPC13xx uses the system PLL to create the clocks for the core and peripherals. On
the LPC134x parts, there is a second, identical PLL to create the USB clock.
