UM10375 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 3 — 14 June 2011 236 of 368
NXP Semiconductors
UM10375
Chapter 13: LPC13xx I2C-bus controller
13.11.4 Slave Transmitter mode
In the slave transmitter mode, a number of data bytes are transmitted to a master receiver
(see Figure 37
). Data transfer is initialized as in the slave receiver mode. When I2ADR
and I2CON have been initialized, the I
2
C block waits until it is addressed by its own slave
address followed by the data direction bit which must be “1” (R) for the I
2
C block to
operate in the slave transmitter mode. After its own slave address and the R bit have been
received, the serial interrupt flag (SI) is set and a valid status code can be read from
I2STAT. This status code is used to vector to a state service routine, and the appropriate
action to be taken for each of these status codes is detailed in Table 238
. The slave
transmitter mode may also be entered if arbitration is lost while the I
2
C block is in the
master mode (see state 0xB0).
If the AA bit is reset during a transfer, the I
2
C block will transmit the last byte of the transfer
and enter state 0xC0 or 0xC8. The I
2
C block is switched to the not addressed slave mode
and will ignore the master receiver if it continues the transfer. Thus the master receiver
receives all 1s as serial data. While AA is reset, the I
2
C block does not respond to its own
slave address or a General Call address. However, the I
2
C-bus is still monitored, and
address recognition may be resumed at any time by setting AA. This means that the AA
bit may be used to temporarily isolate the I
2
C block from the I
2
C-bus.
