Chapter 7: LPC13xx I/O configuration
7.4.18 IOCON_PIO0_6
7.4.19 IOCON_PIO0_7
Table 114. IOCON_PIO0_6 register (IOCON_PIO0_6, address 0x4004 404C) bit description
Bit Symbol Value Description Reset
value
2:0 FUNC Selects pin function. All other values are reserved. 000
0x0 Selects function PIO0_6.
0x1 Selects function USB_CONNECT
(function not available on
all parts).
0x2 Selects function SCK0 (only if pin PIO0_6/USB_CONNECT
/
SCK0 selected in Table 139
).
4:3 MODE Selects function mode (on-chip pull-up/pull-down resistor
control)
10
0x0 Inactive (no pull-down/pull-up resistor enabled)
0x1 Pull-down resistor enabled
0x2 Pull-up resistor enabled
0x3 Repeater mode
5 HYS Hysteresis 0
0 Disable
1 Enable
9:6 - - Reserved 0011
10 OD Selects pseudo open-drain mode. 0
0 Standard GPIO output
1 Open-drain output
31:11 - - Reserved -
Table 115. IOCON_PIO0_7 register (IOCON_PIO0_7, address 0x4004 4050) bit description
Bit Symbol Value Description Reset
value
2:0 FUNC Selects pin function. All other values are reserved. 000
0x0 Selects function PIO0_7.
0x1 Select function CTS
.
4:3 MODE Selects function mode (on-chip pull-up/pull-down resistor
control)
10
0x0 Inactive (no pull-down/pull-up resistor enabled)
0x1 Pull-down resistor enabled
0x2 Pull-up resistor enabled
0x3 Repeater mode
5 HYS Hysteresis 0
0 Disable
1 Enable
9:6 - - Reserved 0011
