Chapter 1: LPC13xx Introductory information
• System PLL allows CPU operation up to the maximum CPU rate without the need for
a high-frequency crystal. May be run from the system oscillator or the internal RC
oscillator.
• For USB (LPC1342/43), a second, dedicated PLL is provided.
• Code Read Protection (CRP) with different security levels.
• Unique device serial number for identification.
• Available as 48-pin LQFP package and 33-pin HVQFN package.
1.4 Ordering options
Table 1. Ordering information
Type number Package
Name Description Version
LPC1311FHN33 HVQFN33 HVQFN33: plastic thermal enhanced very thin quad flat package; no
leads; 33 terminals; body 7  7  0.85 mm
n/a
LPC1311FHN33/01 HVQFN33 HVQFN33: plastic thermal enhanced very thin quad flat package; no
leads; 33 terminals; body 7  7  0.85 mm
n/a
LPC1313FHN33 HVQFN33 HVQFN33: plastic thermal enhanced very thin quad flat package; no
leads; 33 terminals; body 7  7  0.85 mm
n/a
LPC1313FHN33/01 HVQFN33 HVQFN33: plastic thermal enhanced very thin quad flat package; no
leads; 33 terminals; body 7  7  0.85 mm
n/a
LPC1313FBD48 LQFP48 LQFP48: plastic low profile quad flat package; 48 leads; body 7  7 
1.4 mm
SOT313-2
LPC1313FBD48/01 LQFP48 LQFP48: plastic low profile quad flat package; 48 leads; body 7  7 
1.4 mm
SOT313-2
LPC1342FHN33 HVQFN33 HVQFN33: plastic thermal enhanced very thin quad flat package; no
leads; 33 terminals; body 7  7  0.85 mm
n/a
LPC1342FBD48 LQFP48 LQFP48: plastic low profile quad flat package; 48 leads; body 7  7 
1.4 mm
SOT313-2
LPC1343FHN33 HVQFN33 HVQFN33: plastic thermal enhanced very thin quad flat package; no
leads; 33 terminals; body 7  7  0.85 mm
n/a
LPC1343FBD48 LQFP48 LQFP48: plastic low profile quad flat package; 48 leads; body 7  7 
1.4 mm
SOT313-2
Table 2. Ordering options for LPC13xx
Type number Flash Total
SRAM
USB Power
profiles
UART
RS-485
I
2
C/
Fast+
SSP ADC
channels
Pins Package
LPC1311FHN33 8 kB 4 kB - no 1 1 1 8 33 HVQFN33
LPC1311FHN33/01 8 kB 4 kB - yes 1 1 1 8 33 HVQFN33
LPC1313FHN33 32 kB 8 kB - no 1 1 1 8 33 HVQFN33
LPC1313FHN33/01 32 kB 8 kB - yes 1 1 1 8 33 HVQFN33
LPC1313FBD48 32 kB 8 kB - no 1 1 1 8 48 LQFP48
LPC1313FBD48/01 32 kB 8 kB - yes 1 1 2 8 48 LQFP48
LPC1342FHN33 16 kB 4 kB Device no 1 1 1 8 33 HVQFN33
