Chapter 7: LPC13xx I/O configuration
7.4.3 IOCON_nRESET_PIO0_0
7.4.4 IOCON_PIO0_1
Table 99. IOCON_nRESET_PIO0_0 register (IOCON_nRESET_PIO0_0, address 0x4004
400C) bit description
Bit Symbol Value Description Reset
value
2:0 FUNC Selects pin function. All other values are reserved. 000
0x0 Selects function RESET
.
0x1 Selects function PIO0_0.
4:3 MODE Selects function mode (on-chip pull-up/pull-down resistor
control)
10
0x0 Inactive (no pull-down/pull-up resistor enabled)
0x1 Pull-down resistor enabled
0x2 Pull-up resistor enabled
0x3 Repeater mode
5 HYS Hysteresis 0
0 Disable
1 Enable
9:6 - - Reserved 0011
10 OD Selects pseudo open-drain mode. 0
0 Standard GPIO output
1 Open-drain output
31:11 - - Reserved -
Table 100. IOCON_PIO0_1 register (IOCON_PIO0_1, address 0x4004 4010) bit description
Bit Symbol Value Description Reset
value
2:0 FUNC Selects pin function. All other values are reserved. 000
0x0 Selects function PIO0_1.
0x1 Selects function CLKOUT.
0x2 Selects function CT32B0_MAT2.
0x3 Selects function USB_FTOGGLE (function not available on
all parts)
4:3 MODE Selects function mode (on-chip pull-up/pull-down resistor
control)
10
0x0 Inactive (no pull-down/pull-up resistor enabled)
0x1 Pull-down resistor enabled
0x2 Pull-up resistor enabled
0x3 Repeater mode
5 HYS Hysteresis 0
0 Disable
1 Enable
9:6 - - Reserved 0011
