Page #201 background image
UM10375 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 3 — 14 June 2011 201 of 368
NXP Semiconductors
UM10375
Chapter 12: LPC13xx UART
12.6.15.1.1 Example 1: UART_PCLK = 14.7456 MHz, BR = 9600
According to the provided algorithm DL
est
= PCLK/(16 x BR) = 14.7456 MHz / (16 x 9600)
= 96. Since this DL
est
is an integer number, DIVADDVAL = 0, MULVAL = 1, DLM = 0, and
DLL = 96.
12.6.15.1.2 Example 2: UART_PCLK = 12 MHz, BR = 115200
According to the provided algorithm DL
est
= PCLK/(16 x BR) = 12 MHz / (16 x 115200) =
6.51. This DL
est
is not an integer number and the next step is to estimate the FR
parameter. Using an initial estimate of FR
est
= 1.5 a new DL
est
= 4 is calculated and FR
est
is recalculated as FR
est
= 1.628. Since FRest = 1.628 is within the specified range of 1.1
and 1.9, DIVADDVAL and MULVAL values can be obtained from the attached look-up
table.
The closest value for FRest = 1.628 in the look-up Table 210
is FR = 1.625. It is
equivalent to DIVADDVAL = 5 and MULVAL = 8.
Based on these findings, the suggested UART setup would be: DLM = 0, DLL = 4,
DIVADDVAL = 5, and MULVAL = 8. According to Equation 3
, the UART’s baud rate is
115384. This rate has a relative error of 0.16% from the originally specified 115200.
12.6.16 UART Transmit Enable Register (U0TER - 0x4000 8030)
In addition to being equipped with full hardware flow control (auto-cts and auto-rts
mechanisms described above), U0TER enables implementation of software flow control.
When TxEn = 1, UART transmitter will keep sending data as long as they are available. As
soon as TxEn becomes 0, UART transmission will stop.
Table 210. Fractional Divider setting look-up table
FR DivAddVal/
MulVal
FR DivAddVal/
MulVal
FR DivAddVal/
MulVal
FR DivAddVal/
MulVal
1.000 0/1 1.250 1/4 1.500 1/2 1.750 3/4
1.067 1/15 1.267 4/15 1.533 8/15 1.769 10/13
1.071 1/14 1.273 3/11 1.538 7/13 1.778 7/9
1.077 1/13 1.286 2/7 1.545 6/11 1.786 11/14
1.083 1/12 1.300 3/10 1.556 5/9 1.800 4/5
1.091 1/11 1.308 4/13 1.571 4/7 1.818 9/11
1.100 1/10 1.333 1/3 1.583 7/12 1.833 5/6
1.111 1/9 1.357 5/14 1.600 3/5 1.846 11/13
1.125 1/8 1.364 4/11 1.615 8/13 1.857 6/7
1.133 2/15 1.375 3/8 1.625 5/8 1.867 13/15
1.143 1/7 1.385 5/13 1.636 7/11 1.875 7/8
1.154 2/13 1.400 2/5 1.643 9/14 1.889 8/9
1.167 1/6 1.417 5/12 1.667 2/3 1.900 9/10
1.182 2/11 1.429 3/7 1.692 9/13 1.909 10/11
1.200 1/5 1.444 4/9 1.700 7/10 1.917 11/12
1.214 3/14 1.455 5/11 1.714 5/7 1.923 12/13
1.222 2/9 1.462 6/13 1.727 8/11 1.929 13/14
1.231 3/13 1.467 7/15 1.733 11/15 1.933 14/15
